5m3 16 Bar Liquid Oxygen Cryogenic Storage Vessels

Brand Name : GNEE

Certification : SGS

Place of Origin : CHINA

MOQ : ≥1sets

Payment Terms : L/C,T/T

Delivery Time : Transit time: Est. 17-24 days

Packaging Details : Wooden box packaging / Outer shell packaging

Capacity : 5-250 cubic metre

Weight : Specification

Warranty : 1 Year

Dimension(l*w*h) : Actual Size,Customerized

Material : Stainless Steel

Color : white or based on customer's requirement

Medium : LN2 Liquid Nitrogen,LAR,LIN,LN2,Liquified ethylene and etc

Usage : Store,cryogenic liquid storage,liquid gas storage tank,Cryogenic Storage Tank,cryogenic storage dewar

Application : pharmaceutical,Fuel Oil,Cold storage,Chemical,juice

Working pressure : 0.8bar/1.6bar

Working medium : LN2,LO2,LPG,LNG,LAr

Pressure : 10~50kPa

Contact Now

5m3 16Bar Cryogenic tank Storage Lox Cryogenic Liquid Oxygen Tank

Description of cryogenic liquid storage tank

cryogenic liquid storage tank is double-walled; the inner material adopted stainless steel,the outer material is Q345R carbon steel. It concludes vertical and horizontal structure, adopting the use of vacuum powder adiabatic, with the advantage of compact structure , low issuance date,small footprint, centralized control, safety, reliability, and easy operation and maintenance.

Product Specifications

Volume

(M3)

Working Pressure

(MPa)

Working Medium

Weight

(KG)

Size(mm)

5

0.8

liquid oxygen

liquid nitrogen

liquid argon

3412

Φ2000*5130

10

5378

Φ2100*7170

15

6415

Φ2500*6912

20

8255

Φ3000*6100

30

12899

Φ2900*8870

50

18960

Φ3100*12058

100

34480

Φ3600*15947

150

53500

Φ3600*23000

200

65500

Φ3924*26000

5

1.6

liquid oxygen

liquid nitrogen
liquid argon

3945

Φ2000*5130

10

6787

Φ2000*7895

15

8628

Φ2400*7552

20

10744

Φ2400*9371

25

13500

Φ2700*8980

30

14640

Φ2700*10310

50

23370

Φ3100*12058

100

44050

Φ3400*17930

5m3 16 Bar Liquid Oxygen Cryogenic Storage Vessels

5m3 16 Bar Liquid Oxygen Cryogenic Storage Vessels

5m3 16 Bar Liquid Oxygen Cryogenic Storage Vessels

Our product Advantages

Best Raw Materials
The raw materials are high-strength steel plates specially used for pressure equipment, which are directly customized from first-tier steel mills at home and abroad. The materials are traceable, and the high cost guarantees high quality.

5m3 16 Bar Liquid Oxygen Cryogenic Storage Vessels

Uniform Weld Seam Appearance
With argon-shielded welding, the weld seam has a uniform appearance. The transitions between weld beads and between weld beads and base metals are smooth.

5m3 16 Bar Liquid Oxygen Cryogenic Storage Vessels

4-Layer Painting
A 4-layer paint spraying process is adopted to ensure the anti-corrosion performance and service life of the equipment.

5m3 16 Bar Liquid Oxygen Cryogenic Storage Vessels

Advanced Testing Technology
100% re-inspection is conducted on raw materials and accessories when they enter the factory. Ultrasonic internal quality testing, mechanical property testing, chemical composition testing, and impact performance testing are carried out to ensure the quality of the tanks.

5m3 16 Bar Liquid Oxygen Cryogenic Storage Vessels
